Fat 2.4 tyres provide plenty of comfort and grip 7 speeds with rapid-fire shifters keep things simple and Tektro hydraulic disc brakes take care of the stopping. Approx 9.5kg.
Highlights:
It’s all about lightweight for kids; all our bikes have rigid forks as cheap suspension forks tend to work poorly and weigh a lot. We use 1x drivetrains with rapid-fire shifters to keep shifting simple, further reducing the overall weight. All components are as light and child-focused as possible. The flip-flop stem and spacers allow for growth, extending the life of the bike. Suits heights from approx. 109-129 cm.
Frame |
TFS - 6061 aluminium tubing, double butted and technoformed. BSA BB standard, 9mm QR axle standard. Replaceable dropout. Max tyre size 20 x 2.4 |
Fork |
Merida Matts J. 20+; aluminium. Max tyre size: 20 x 2.4 |
Gears |
7 |
Shifters |
Shimano SL-M315-7 |
Rear Derailleur |
Shimano RD-TY300 |
Bottom Bracket |
FSA TH-7420ST, 68-124 |
Chain |
KMC Z8.3 |
Chainset |
Merida Expert JR; 28 tooth chainset; Aluminium; Crank length - 127mm |
Cassette |
Shimano MF-TZ500; 14-34 teeth; 7 speed |
Brake Lever |
Tektro M275 |
Front Brake |
Tektro M275; hydraulic disc brake caliper with Tektro TR160; 160mm rotor |
Rear Brake |
Tektro M275; hydraulic disc brake caliper with Tektro TR140; 140mm rotor |
Grip |
Merida Expert JR |
Handlebar |
Merida Expert JR; aluminium; 620mm wide; 0mm rise |
Stem |
Merida CC; aluminium; 31.8mm diameter; 6 degree rise - Length - 60 mm |
Head Set |
FSA NO.10P Neck15 |
Pedal |
Marwi SP-202 |
Saddle |
Merida Comp Jr. |
Seat Post |
Merida Comp CC; 27.2mm diameter; 0mm layback; Aluminium |
Wheel Size |
20 |
Rims |
Merida Jr. 20+; aluminium |
Spokes |
Black steel |
Front Hub |
KT-K68F; 100 x 9mm; 20 spoke |
Rear Hub |
Joytech D242DSE; 135 x 9mm; 24 spoke |
Front Tyre |
CST Jet C1820; 20 x 2.4; wire bead |
Rear Tyre |
CST Jet C1820; 20 x 2.4; wire bead |
Colour |
Matt Mint/Purple/White/Black |
